How I Upgraded A Production Grade Kubernetes Cluster From 1.22 To 1.23.17 using Kubeadm

0

Kubernetes, image credit - thelinuxnotes

In this article, I will share my experience in upgrading a bare metal Production grade Kubernetes cluster from 1.22 -> 1.23.17 using Kubeadm. The process is quite straightforward, however, there are some gotchas I encountered and I have documented them here, which may be helpful to you.

The process is in 2 parts:

• Upgrade the Control Plane Nodes
• Upgrade the Worker Nodes

First, run kubectl get nodes -o wide to see all the nodes.

Kubernetes Control Plane Upgrade: 1.22 -> 1.23.17

• Drain the node:

kubectl drain --ignore-daemonsets --delete-emptydir-data <node>

• ssh into the node

ssh -i ~/.ssh/key <user>@<ip>

For The First Master Node

• Run the following command to list the available k8s versions:

apt-cache madison kubeadm | grep 1.23

• Run upgrade kubeadm

apt-mark unhold kubeadm && apt-get install -y kubeadm='1.23.17-00' && apt-mark hold kubeadm

• You may need to get the kubeadm-config file:

kubectl get cm/kubeadm-config -o yaml -n=kube-system

#~/kubeadm-config-1.23.yaml

apiServer:
  extraArgs:
    authorization-mode: Node,RBAC
  timeoutForControlPlane: 4m0s
apiVersion: kubeadm.k8s.io/v1beta3
certificatesDir: /etc/kubernetes/pki
clusterName: kubernetes
controlPlaneEndpoint: <ip>:<port>
controllerManager: {}
dns: {}
etcd:
  local:
    dataDir: /var/lib/etcd
#imageRepository: k8s.gcr.io
imageRepository: registry.k8s.io
kind: ClusterConfiguration
kubernetesVersion: v1.22.0
networking:
  dnsDomain: cluster.local
  podSubnet: <ip>/16
  serviceSubnet: <ip>/12
scheduler: {}

• Run the command to upgrade the node:

kubeadm upgrade apply v1.23.17 --config ~/kubeadm-config-1.23.yaml --ignore-preflight-errors=CoreDNSUnsupportedPlugins

• Run the command to upgrade kubelet and kubectl

apt-mark unhold kubelet kubectl && apt-get install -y kubelet='1.23.17-00' kubectl='1.23.17-00' && apt-mark hold kubelet kubectl

• Uncordon the node:

kubectl uncordon <node>

For Each Of The Rest Of The Master Nodes

• Drain the node:

kubectl drain --ignore-daemonsets --delete-emptydir-data <node>

• ssh into the node

ssh -i ~/.ssh/key <user>@<ip>

• Check available kubelet & kubectl versions(Minor version upgrade is ok e.g 1.23.14):

apt-cache madison kubeadm | grep 1.23

• Run upgrade kubeadm

apt-mark unhold kubeadm && \
apt-get install -y kubeadm='1.23.17-00' && \
apt-mark hold kubeadm

• Run the command to upgrade the node:

kubeadm upgrade node --ignore-preflight-errors=CoreDNSUnsupportedPlugins

• Run the command to upgrade kubelet and kubectl:

apt-mark unhold kubelet kubectl && apt-get update && \
apt-get install -y kubelet='1.23.17-00' kubectl='1.23.17-00' && \
apt-mark hold kubelet kubectl

• Uncordon the node:

kubectl uncordon <node>

Kubernetes Worker Upgrade: 1.22 -> 1.23.17

• Drain the node:

kubectl drain --ignore-daemonsets --delete-emptydir-data <node>

For Each Of The Worker Nodes

• ssh into the node:

ssh -i ~/.ssh/key <user>@<ip>

• Run the following command to list the available k8s versions:

apt-cache madison kubeadm | grep 1.23

• Run the command to upgrade kubeadm, kubelet and kubectl:

apt-mark unhold kubeadm && apt-get install -y kubeadm='1.23.17-00' && apt-mark hold kubeadm && kubeadm upgrade node && apt-mark unhold kubelet kubectl && apt-get install -y kubelet='1.23.17-00' kubectl='1.23.17-00' && apt-mark hold kubelet kubectl && systemctl daemon-reload && systemctl restart kubelet

• Uncordon the node:

kubectl uncordon <node>

At this point, we have successfully upgraded the Kubernetes cluster from 1.22 -> 1.23.17.
